Flame-retardant wire and cable materials have become indispensable key components in building, transportation, energy, and data infrastructure due to their advantages in controlling flame spread, reducing toxic smoke, and ensuring personnel safety.
These materials not only safeguard human lives in public spaces but also directly impact corporate compliance and the construction and operation of infrastructure.
So where exactly do flame-retardant cable materials play a critical role? Let's delve into the key application areas where these materials ensure performance and compliance.
Building fires can spread rapidly through cable trays and shafts. Without flame-retardant materials, burning cables not only fuel the fire but also release toxic fumes.
In the construction sector, flame-retardant cable materials ensure:
*Flames within wiring systems are contained and prevented from spreading along cables;
*Low smoke emission during fires;
*Compliance with global safety standards.
Cables within building walls and ceilings can form vertical flame pathways, particularly in commercial, residential, and public areas. Cables with traditional PVC insulation are flammable and drip molten material, increasing the risk of igniting other combustible items. In contrast, low-smoke, zero-halogen (LSZH) flame-retardant cable materials are self-extinguishing and release minimal acidic gases when ignited, significantly enhancing evacuation safety.
IEC 60332: Controlling flame spread
IEC 60754: Limiting halogen acid gas release
IEC 61034: Smoke density testing
These tests are mandatory requirements for high-rise buildings, hospitals, airports, and commercial spaces.
| Building Types | Cable Types | Key Flame Retardant Requirements |
| High-rise Buildings | Power, Control | Complies with LSZH standards and meets IEC 60332-3 specifications |
| Hospitals | Data, Alarm | Low smoke and low toxicity, conforms to CPR directive requirements |
| Transportation Hubs | Signal, Power | Complies with EN 45545 standards and satisfies IEC 61034 smoke control requirements |
Due to limited interior space and extreme evacuation challenges during fires, flame-retardant cables are particularly critical in railways, subways, automobiles, electric vehicles, aerospace, and marine applications.
Flame-retardant cable materials in this sector must meet:
Low smoke and non-toxic gas characteristics
Self-extinguishing properties
Compliance with EN 45545, FAR 25.853, and marine standards
Must comply with EN 45545 HL1–HL3 (low smoke, low toxicity, low heat release)
LSZH cables are required in tunnels and underground stations to ensure visibility during fires
ISO 6722 and LV112 are primary testing standards
High-voltage, high-current environments in new energy vehicles drive flame-retardant materials toward enhanced heat resistance and lightweighting
Aircraft cables: Require lightweight construction and high reliability, compliant with FAR 25.853
Marine cables: Must meet IEC 60332-3, IEC 61034, IEC 60754 to prevent accumulation of corrosive gases in engine compartments
| Fields | Standards | Key Requirements |
| Rail Transportation | EN 45545 HL1–HL3 | Smoke ≤60%, low toxicity, low heat release |
| Automotive | ISO 6722, LV112 | Flame retardancy, insulation integrity |
| Aerospace | FAR 25.853 | Flame ≤60 seconds, smoke <200 Ds |
| Marine | IEC 60332-3, 60754 | Halogen-free low smoke (LSZH), corrosion resistance |
Rise of Electric Mobility: Rapid EV Growth Drives Demand for High-Performance Flame-Retardant Cables
Low-Carbon & Lightweighting: Aerospace and Automotive Industries Fuel Development of Novel Flame-Retardant Polymers
Data centers, petrochemical plants, and industrial facilities demand uninterrupted operation.
Fires not only threaten personnel safety but can also cause prolonged downtime and significant economic losses.
Flame-Retardant Cable Materials in These Sectors Must Meet:
Minimized smoke and low halogen gas emission, or even halogen-free gas release;
Suppression of fire spread in high-density cable trays;
Compliance with UL 1685, NFPA 262, and IEC 60332 standards;
Key certification standards:
UL 1685: Flame spread and smoke index testing for tray cables
NFPA 262: Tunnel fire test applicable to buildings and IT facilities
*Hyperscale data center construction drives increased demand for flame-retardant materials
*5G and AI infrastructure expansion requires higher cabling density and more stringent material performance specifications
| Applications | Standards | Primary Safety Objectives |
| Data Centers | UL 1685, NFPA 262 | Low smoke, halogen-free, minimal flame spread |
| Oil and Gas | IEC 60332-3 | High oxygen index, chemical resistance |
| Automation Industry | UL 94 V-0 | Rapid self-extinguishing, mechanical durability |
Selecting appropriate flame-retardant compounds is not only a technical requirement but also a matter of corporate social responsibility.
Compliance with international regulations to reduce market access barriers
Ensuring personnel and property safety
Mitigating legal risks for contractors and OEM manufacturers
Flame-retardant wire and cable materials have evolved from a “safety-related value-add” to a fundamental, strategic safeguard. With accelerated urbanization, smart transportation, and digital infrastructure development, market demand for high-performance, eco-friendly, and compliant flame-retardant materials will continue to grow.
>>Do you require LSZH cable compounds compliant with EN 45545 or IEC 60332 standards?<<
>>Contact us immediately to obtain the latest sample formulations and technical data sheets.<<
